GRP Booster Set Grand Enclosure PWHG.2.5x2.5x2.5
This product is specified and quoted to your requirements. Send us the details and our team will come back to you with a full price, including delivery.
Request a quote- Response within one working day
- No obligation
- Speak to a specialist on 01643 703358
GRP Booster Set Grand Enclosure PWH.2.5x2.5x2.5
Our GRP enclosures are suitable for the protection of a number of items of industrial equipment, including our own water storage tanks, pump sets, valves in fact there is a housing to suit virtually any industrial product.
Used by Gas, Water and Electricity providers and local authorities along with the Mechanical services industry and many others.
General Construction
Our GRP housings are manufactured from the highest quality GRP materials to withstand the rigours of the harshest weather conditions.
All enclosures have a tough weather resistant polyester gel coat outer, reinforced with a GRP laminate incorporating an encapsulated polyurethane foam core to provide insulation. External colour options are RAL6005 Green or BS 00A05 Industrial Grey. Other colours are available on request.
Insulation is 18 mm thick as standard. This can be increased to 50 mm for extreme temperature applications.
Internal finish is a durable polyester gel coat finish in white.
Configurations start as small as 1860 x 1860 x 2000 mm high, up to infinite size.
Available as one-piece units for smaller applications or in sections in 500 mm increments in length and wiIXO-DTh up to a height of 3 metres.
Door furniture includes stainless steel hinges and fixings, Yale type night latch lock assemblies, External door handles, internal door check straps and stays.
Features and Benefits
- One-Piece Construction requiring no on-site assembly
- Low maintenance, durable construction
- Locking door with Cylinder night latch
- Internally flanged to allow fixing down to foundation
- Available in a range of external colours to allow matching with other equipment
| L x W x H (mm) | |
| Internal Dimensions | 2360 x 2360 x 2500 |
| External Dimensions | 2575 x 2575 x 2700 |
| Door Configuration | Double 1600 x 2000 High |
| Internal Ply mounting Board | Included 1220 x 1220 |
| Louvered Vents | 2 x Included 300 mm x 300 mm |
| Lifting Eyes | 4 Included |
PWHG.2.5x2.5x2.5 (50mm Insulation) Dimensions
| L x W x H (mm) | |
| Internal Dimensions | 2200 x 2200 x 2500 |
| External Dimensions | 2575 x 2575 x 2700 |
| Door Configuration | Double 1600 x 2000 High |
| Internal Ply mounting Board | Included 1220 x 1220 |
| Louvered Vents | 2 x Included 300 mm x 300 mm |
| Lifting Eyes | 4 Included |
Protection and concealment of a range of products
- Water Storage Tanks
- Pump Stations and Booster Sets
- Water treatment equipment
- Electrical Equipment
- Control Equipment for the water supply and waste water industry
- RPZ Valve Protection
Product range
- Smaller GRP enclosures are available as a single piece unit, which are normally delivered to site palletised and only require fixing down to a structural slab or raised kerbing.
- Larger enclosures are constructed in a metric modular format and can be assembled at our works for delivery as a single unit or, where access restrictions apply, be supplied in sections to allow assembly on site.
- On site assembly is carried out by our own, directly employed engineers. Purewater do not use subcontract labour for enclosure assembly.
Accessories
- Encapsulated ply backing boards for electrical components and switchgear.
- Screened spill over screens to the housing walls (to comply with water regulations, back flow prevention).
- Factory prepared pad areas to allow for pipework to pass through housing walls.
- Single or double door assemblies.
- Access man ways to housing roof for applications where space restrictions apply.
*Please note that the booster set is not included with this unit, it's the enclosure only
Enquiries
Please contact us and let us know the size of the GRP housing or enclosure required along with any site specific details, such as access restrictions which may apply, and we will be happy to provide a detailed quotation.
Delivery
All our GRP Grand Enclosures are for delivery by 26t HIAB only, so will need suitable access for this size of vehicle. Please contact us for price for delivery to your location.
| Empty Weight | 350 kg |
|---|---|
| Material | GRP / Fibreglass |
Electric Fit Out Kit A
- Light Switch on opening leaf x 1
- Double Socket 13A 240v RCD x 1
- 58W x 1500 Fluorescent tubes in IP56 Fittings x 1
- LV distribution board 2 way 100A SP MCB board x 1
Electric Fit Out Kit B
- Light Switch on opening leaf x 1
- Double Socket 13A 240v RCD x 1
- Double Socket 13A 240v x 1
- Un-swiitched Fused Spur x 1
- Switched Fused Spur x 1
- 58W x 1500 Fluorescent tubes in IP56 Fittings x 3
- LV Distribution board 5 way 100A SP MCB board x 1
Electric Fit Out Kit C
- Light Switch on opening leaf x 1
- Double Socket 13A 240v RCD x 3
- Double Socket 13A 240v x 1
- Un-swiitched Fused Spur x 25
- 58W x 1500 Fluorescent tubes in IP56 Fittings x 3
- LV Distribution board 5 way 100A SP MCB board x 1
- Tube Heater C/W Thermostat x 1
Please note, all the above packs are based on Installation with the enclosures at the factory prior to delivery. If installation is required on site, please contact us, as this will incur additional costs
