PIR Flush Mount Senso, 230VAC
Product Ref: PIRFLUSH230V
Product Description
PIR Flush Mount Sensor (230VAC)
A PIR (Passive Infrared) sensor detects changes in the amount of infrared radiation, which varies depending on the temperature and surface characteristics of an object in front of it. This ensures that water is only supplied when required, therefore preventing minor water leaks from accumulating into large amounts of waste water.
When an object, such as a human, passes in front of a different background (such as a wall) the temperature at that point in the sensor's field of view will rise.
The sensor converts the resulting change into an output voltage, and this triggers the detection. When the PIR is linked to a solenoid valves installed on the incoming water suppliers, water can only flow when the WC area is occupied.
Technical Specification:
- Voltage - 230V Ac 50Hz
- Range - 6m Diameter at 2.5m High
- Detection Angle - 360°
- Max Switch Load - 2000W Halogen/ 500W Fluorescent
- Time on adjust - 5 Sec - 18 mins
- Protection - IP44
Features
- Up to 6 Valves can be connected to a single PIR sensor
- Multiple PIR sensors can be connected to a single valve
- Discrete flush mount PIR sensors
- Designed for WC areas
- Meets the requirements of BREEAM WAT03 flow control
