Ecosom E Solar Water Pump Set Up



Product Ref: ECOSOM E

Customer Offloading Fast Delivery Solar Power

Home Delivery

UK mainland delivery from £65.00 ex VAT

check delivery cost

updown

Component Spec

Battery 12V 100 Ah:

  • 100 Ah 12 V AGM Long-Life,
  • monobloc,
  • Maintenance-free;
  • 120 minutes of pumping life (160 minutes with SF190 pump);
  • 8 hours to charge totally with pump in stand-by.

Solar Modules:

  • 2 x 180 Wp (+/- 3%) monocrystalline silicon solar cells supplied with fixing bars and frame

Downloadable Documents

Product Description

ECOSOM E

ECOSOM solar stations are easy-to-install pumping units that can be used wherever there is a good amount of sunlight.

The solar panels supplied with the power station will recharge the batteries so that power can be provided to the pumps even when no solar power is available. These solar stations can be combined with pumps listed above, these are all 24V DC pumps with permanent magnet motors.

The ECOSOM E station comes complete with the following

  • Fibreglass cabinet (for installing outdoors)
  • Hand - off - auto selector switch
  • 30 A unipolar thermal protector switch
  • 80 A power relay
  • Indicator lights for: run - pump cut-out - low battery cut-out
  • 20 A automatic charge controller to provide the correct power to the batteries.
  • Fuse holder with fuses on both main and auxiliary circuit

Control Panel Specifications

  • IP rating IP44
  • Ambient temperature -5/+40 °C
  • Suitable for external installation
  • Can be installed on the base of the fixing frame (if ordered)
  • Easy-to-inspect battery location
  • Facility to wire float switches for dry running protection
  • Facility to wire pressure switch, stop and run float switch, etc.

Without the options ordered, this package includes the control panel, cabinet, solar panels and the wiring.

Please note that this product does not come with a tank for the pumps to sit inside.

We do need to point out that we do not recommend these products for use in normal domestic settings, as there can be no guarantees offered around the availability of solar energy to charge the batteries. Therefore, it is recommended that these are only used in off-grid situations where there is no other option.





Product Details

  • Product Code: DPT
  • Customer Offloading: Customer Offloading
  • Delivery: Fast Delivery
  • Power: Solar Power

Pump Info

    P2 P1 Max
  HP Kw Kw A Battery Life (min)
RF80/04/1 0.75 0.55 0.67 28 120
SF190 0.5 0.37 0.58 24 160
SF320 0.75 0.55 0.67 28 120
SF290 0.75 0.55 0.67 28 120
SF262 0.75 0.55 0.67 28 120



  Flow
  m³/h 0 0.36 0.6 1.2 1.8 2.4 3 3.6 4.2 4.8
  l/min 0 6 10 20 30 40 50 60 70 80
RF80/04/1 Head (m) 40 38 37 34 30 26 21 17 11 7



  Flow
  m³/h 0 1.8 6 9 12 15 18 21 24
  l/min 0 30 100 150 200 250 300 350 400
SF190 Head (m) 10.5 9.5 7 4 1
SF320 11.5 11 9 7.5 5.5 3 0.5
SF290 8.5 8 7 6.5 5.5 4.5 3.5 2.5 1
SF262 10.5 10 9 8 7 6 4.5 3 1
