Clearwater BioAir CW3 Sewage Treatment Plant - 9 Person
Product Ref: BIA3UGEB
Estimated Lead Time: 3 to 5 working days
login to save
Clearwater BioAir Datasheet Feb24Product Description
Clearwater BioAir CW3 Sewage Treatment Plant - 9 Person
Available as Gravity or Pumped outlet options, the new Clearwater CW3 BioAir sewage treatment plant employs aerated technology, delivering a high level of water discharge quality.
With adaptable installation choices to accommodate diverse domestic locations and a discreet visual profile, the Clearwater BioAir stands as a financially sensible option for your household wastewater treatment needs.
Product Benefits:
- Affordable
- Suitable for shallow dig Installations
- Flexible installation & lightweight robust design
- Low impact visual footprint
- Supplied with isolator switch and failure light (High Level Alarm optional on IPS unit)
- 1 year warranty* (terms apply)
Typical Applications
- Single & Multiple Homes
- Barn Conversions
- Small Offices
- Farms
MAXIMUM INLET INVERT USING:
Gravity Units: Max Invert: 1400mm Pumped Units: Max Invert: 1000mm
For Inverts from 755 - 1200mm order 1 X BPAEXT13
For Inverts from 1200 - 1400mm order 2 X BPAEXT13
*Please click on the following link to register your warranty.
https://www.kingspan.com/gb/en-gb/products/wastewater-management/guarantee
Delivery
All our Clearwater tanks are for delivery by customer offload. This entails the customer to acquire the right manpower and/or machinery to help unload the tank/s from the delivery vehicle.
If you require assistance with offloading, we may be able to offer a tail lift (lowers the tank to the ground) or HIAB (lorry with a mounted crane to winch the tank off to the nearest hardstanding area only, at an additional cost). Please contact us if this is required for delivery.
Product Details
- Product Code: CLW
- Customer Offloading: Customer Offloading
- Delivery: Fast Delivery
- Diameter: 1540mm
- Free Site Survey: Free Site Survey
- HIAB Available: HIAB Available
- Material: MDPE
- Stock tank: Stock tank
- Tank Use: Below Ground, Sewage
Do you require Commissioning?
To ensure your system operates to maximum efficiency, we recommend tried and tested Commissioning by our own British Water and Safe Building trained engineers.
Our unrivalled knowledge means that we are best placed to carry out bespoke assessments to get your system up and running. The commissioning will also provide you with a unique checklist against your system, ensuring your complete peace of mind and reassurance that your system's mechanical and electrical components are in good working order.
The checks below will be carried out by a Kingspan Service Engineer and will only be checked if the unit has been installed in line with the provided installation guidelines.
- Check Plant is level, 5 mm tolerance
- Confirm the ground around the plant is level, flat and that the lid securely fastens
- Confirm the panel has been mounted correctly
- Make the required connections to the panel using correct glands
- Make all electrical connections within the tank
- Ensure all safety guards are fitted
- Set all greasomatics within the plant (if applicable)
- Check belt/chain tension and alignment
- Check pump float activates freely (pumped discharge only)
- Check operation of sludge return pump (nitrification plants only)
- Check direction of disc pack
- Check levels within unit
- Test and set any Alarms supplied with the unit
On completion, they will provide a site specific commissioning certificate
Find out more about what's included in the commissioning of your Clearwater sewage treatment plant and arrange Commissioning, read Kingspan's dedicated guide to Commissioning today.
*terms and conditions apply
Delivery
Our shipping costs cover most of the UK - however, parts of England, Scottish Highlands and Islands including areas north of the Glasgow / Edinburgh border, Isle of Wight, Channel Islands, Isle of Man, Anglesey, Western Isles, Shetland Islands, Orkney Islands, Isles of Scilly, Northern Ireland and the Republic of Ireland may cost more.
Please call before ordering if the delivery postcode is listed below. There may be additional shipping costs. AB, BT, CA, CT, DD, DG, EH, FK, G, GY, IM, IV, JE, KA, KW, KY, LD, LL, ML, PA, PH, PO 30-41 (Isle of Wight), SA, SY, TD, TN, TR, ZE Southern Ireland
Our lead times should only be used as a guide and are subject to change.
Offloading
Unless a hi-ab delivery has been booked at additional cost, it is the customer's responsibility to offload with suitable equipment on the day of delivery and a failed delivery may result in additional charges.
We recommend installers and/or plant hire & materials to install such as excavators, aggregates etc are not booked until you are in receipt of the goods. Tanks Direct cannot be held responsible for costs incurred due to unforeseen delays, please see our terms for more details.
HIAB
HIAB delivery will be required if you need the tank offloaded from the delivery vehicle. The driver will unload the tank from the vehicle to ground level, however this service is not to place the tank in situ, this will need to be arranged separately.
If you have any questions regarding your delivery, please contact the Sales Team on 01643 703358.
Returns Information
Please note - Certain items may not be returnable, for example those made to order or for sanitary reasons. Please check the product page for more information.
Customers may return items within 14 calendar days (as per our Terms & Conditions) - refer to section 7. **
All Items must be returned unused, refunds cannot be issued for used or previously installed items.
Please be aware that returning a tank can be complicated and expensive, so please check that you are ordering the correct item (we suggest checking the dimensions very carefully).
If you wish to return goods, please complete the form on this page to provide further information.
Once your request is approved, a valid Returns Authorisation Number (RAN) will be issued to initiate the returns process along with information on how & where to return your order along with any costs involved.
Please DO NOT return any goods without this authorisation. Goods cannot be accepted without this.
Returns are not accepted at our Minehead Office, please wait until we contact you before returning any goods.
