Kingspan Ultrasteel 250 Litre Indirect - Horizontal Unvented Hot Water Cylinder



Product Ref: AUIH250ERP

Customer Offloading Free Delivery
  • Volume: 250ltr
  • Dimensions: L:1696mm H:680mm
  • Diameter: 550mm
  • Home Delivery

    UK mainland delivery from FREE ex VAT

    check delivery cost

    Request a quote

    What is the difference between Direct and Indirect

    Direct is where the heat comes from an electric immersion heater whereas the Indirect heat source uses the heat from a boiler.

    Product Description

    250 Litre Indirect Horizontal - Unvented Hot Water Cylinder - Ultrasteel AUIH180ERP

    Indirect horizontal cylinders are a practical solution for locations where height restrictions apply, such as lofts, enabling for unvented cylinders to be fitted in properties where otherwise it would not be possible. These cylinders are designed to heat up quickly using the coil-in-coil heat exchanger with the heat supplied from a conventional gas, oil or electric boiler. They also feature a 3 kW backup immersion heater, which can act as a boost or a secondary heat source.

    Ultrasteel cylinders deliver high flow rates and mains pressure hot water (regulated up to 3 bar) for powerful showers and the fast filling of baths or sinks, making them ideal for homes with multiple bathrooms or extra utility rooms.
    Manufactured from high-grade engineering materials, such as 'Duplex' stainless steel, for superior corrosion resistance.

    Package includes:

    • Inlet Control Set
    • Temperature & pressure relief valve
    • 15 mm/22 mm Tundish
    • 18 Litre expansion vessels
    • 2 x 3kW Secondary Immersion Heater
    • Product Manual including Benchmark log

    Features and Benefits

    • 50 mm CFC & HCFC-free foam insulation for low heat loss
    • Economical to run with minimal maintenance and no hidden costs
    • Factory fitted temperature & pressure relief valve
    • 22 mm compression connections
    • High quality inlet control set with balanced cold

    Ultrasteel Horizontal 250 Litre Indirect Specifications

     Model  AUIH250ERP
     Nominal Capacity  250 Litres
     Height (mm)  680
     Length (mm)  1696
     Diameter (mm)  550
     Rating  C
     Standing Loss (W)  84
