High Level Alarm for Sewage Pumping Station cw Float



Product Ref: HLATDDP+FLOAT

Estimated Lead time: 2-3 working days

Home Delivery

UK mainland delivery from £19.00 ex VAT

check delivery cost

Downloadable Documents

Product Description

Sewage Pumping Station High Level Alarm with float

The Direct Pumps & Tanks High-Level alarm operates from a switched input, such as a ????oat switch or pressure switch. The alarm can be activated either by a closed circuit switched input or an open circuit switched input.

The High-Level alarm is suitable for 110-240Vac supply voltages and has a built-in backup battery for the unexpected event of a power outage.

Once activated, the alarm provides a visual and audio indicator. There is an option to connect an external beacon or other circuitry via the auxiliary output and/or the volt-free relay output.

A mute button allows the operator to silence the audio alarm of the unit without affecting the visual, auxiliary output or volt-free relay.

A test button conveniently allows the operator to check the alarm functions without the need to trigger the input to the alarm.

Power to the alarm is indicated via a blue constant light, allowing easy operational inspection of the unit. In the event of a power outage, the alarm will still operate for up to 72 hours and the power indicator will ????ash red.

Features:-

  • Alarm LED indicator
  • Alarm audio buzzer
  • Alarm audio mute button
  • Alarm test button
  • Power LED indicator
  • IP65-rated enclosure
  • Auxiliary alarm output for accessories such as a beacon
  • or siren
  • Volt free relay contact output SPDT
  • Configurable for ACTIVE open or ACTIVE closed alarm
  • input
  • Easy installation no tool required WAGO wiring
  • terminals
  • Backup battery with up to 72 hours of run time
